In stock
SKU: YAL005057

Yale TZL Crane Weigher (without Remote Control) Range 0-20 Tonnes

From: £1,340.58
  • Yale NEW Tigrip TZL Crane Weigher.
  • Suitable for weighing loads ranging from 0-100 Tonnes.
  • Measures in Kg, Tonnes, Lbs and kN
  • Automatic 'Zero' function when powered on
  • Battery capacity approx. 200 hours of operation
  • Robust design
  • Lightweight
Final Configuration Price:
From: £1,340.58
Estimated time to dispatch
Estimated time to dispatch: 2-3 Days
  • We Accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Maestro
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa
Shipping & Delivery

We don't send anything by standard post, all of our deliveries are by trusted couriers which are fully traceable to ensure your orders arrive safe and on time.

Delivery Prices & Transit Times

Delivery costs can be found at checkout.

EXPRESS DELIVERY - Next Working Day Courier, delivered between 08:30-17:00

Scottish Delivery: 1-2 Day Courier (after dispatch)

UK Before 10:30AM: (please call first to check availability)

UK Express Saturday Delivery: (please call first to check availability)

Click & Collect: Free!

Channel Islands: 1-3 Day Courier (Jersey, Guernsey and Isle of Man)

Western Europe: (Netherlands, France, Belgium, Spain, Portugal)

Eastern Europe: Find out in checkout

Rest of the world: Find out in checkout

DELIVERY CUT-OFF

  • For all orders placed by 2pm we will endeavour to dispatch same day for delivery the following day.
  • All orders after 2pm will dispatch the following working day.
  • For urgent shipments and 'last minute' requirements, please call our Sales Team -  it's always worth asking if we can still get it out the door today!

Please be aware that some of our products have a lead time, and therefore the quoted transit times above are only applicable after the goods have been dispatched. We always make it clear in the description if our products have a lead time.

We regret that we cannot provide time slots for deliveries unless you have selected pre 10:30AM delivery, all standard express deliveries are delivered between 08:30-17:00 the next working day from dispatch.

Collection of most goods can be made from our warehouse upon request. Did you know that we have a range of slings, shackles and hoists available for instant Click & Collect? While nearly all items on our website can be collected next working day! Call our sales team now on 01384567430

Yale Tigrip Crane Weigher TZL (0-20 Tonnes)

The new generation of Load Cells designed and manufactured by industry experts, Yale. These are quality and exretemely compact units perfectly engineered for the weighing of loads ranging from 0 to 20 Tonnes depending on the model chosen.

The 'TZL' unit is the standard unit featuring a digital display. The TZR model is exactly the same however comes delivered with a remote control (for the TZR series please see related products below).

Due to their unique and flexible design the TZL load indicators can be used for a wide variety of applications. It could be used as a standard crane scale or to measure force of a rigging structure.

The unit boasts an LCD display. It has the functions of 'tare' as well as the ability to show either the net or gross loads. Not only this but it has the added precaution of informing the user of an overload at 110% of the rated capacity and shows the remaining battery life. There are FIVE models in the Yale TZL series. The units each boasts the same features, the only differences are the weight and load capabilities of each.

*Please note shackles aren't supplied as standard. If you require shackles with delivery of this product please see related products
*External battery charger does not come supplied with the unit however, if you wish to have the weigher delivered with this extra please contact our sales team and we can have this arranged for you.



Key features and benefits of the TZL Load Indicator:

  • Simple to set up and use
  • Display is easy to read and comprehend
  • Light weight design
  • Very accurate
  • Can withstand heavy industrial use
  • The housing of the unit can handle rotation on 180 degrees
  • Has an auto setting of ZERO when the unit is switched on
  • Retains the peak value to memory
  • The battery boasts around 200 hours use before replacement is necessary!
  • It is possible to use rechargable batteries (external battery charger*)
  • Displays an 'overload warning' (crucial to safety!)
  • The unit gives a warning when the battery is low
  • Display of MAX weight (be it gross or net)
  • Capable of displaying a variety of measuring units (kg, tonnes, lbs and kN)
  • Auto standby (Significantly prolongs the battery life of the unit)
  • Display of measuring units at load indicator
